1461352-5
Manufacturer:
TE Connectivity
Mfr.Part #:
1461352-5
Datasheet:
Description:
Relays Through Hole Coil Current:16.7 mA Contact Current Rating:5 A SPST Coil Voltage (DC):12 V Coil Voltage (AC):12 V General Purpose 200 mW
| Parameter | Value |
|---|---|
| Length | 20 mm |
| Width | 10 mm |
| Termination | PCB |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 277 V |
| Number of Pins | 5 |
| Height | 15.1892 mm |
| Circuit Type | SPST-NO |
| Packaging | Bulk |
| Depth | 9.9 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Weight | 7 g |
| Contact Material(Contact Finish) | Silver, Tin |
| Current Rating | 5 A |
| Max Voltage Rating (DC) | 30 V |
| Lifecycle Status | Production (Last Updated: 4 days ago) |
| Number of Contacts | 1 |
| ELV | Compliant |
| Ambient Temperature Range High | 85 °C |
| Throw Configuration | SPST |
| Max Voltage Rating (AC) | 277 V |
| Coil Voltage (DC) | 12 V |
| Coil Current | 16.7 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 720 Ω |
| Relay Type | General Purpose |
| Operate Time | 10 ms |
| Release Time | 5 ms |
| Contact Current Rating | 5 A |
| power consumption | 200 mW |
| Termination Style | PC Pin |
| Switching Voltage | 277 V |
| Coil Power | 200 mW |
| Coil Voltage (AC) | 12 V |
| Contact Voltage Rating (AC) | 277 V |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 4 days ago) |
| Must Operate Voltage | 9 V |
| Must Release Voltage | 600 mV |
Stock: 23
Distributors
pcbx
pcbxUnit Price$1.57728
Ext.Price$1.57728
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.57728 | $1.57728 |
| 10 | $1.32816 | $13.28160 |
| 25 | $1.22670 | $30.66750 |
| 50 | $1.13299 | $56.64950 |
| 100 | $1.04644 | $104.64400 |
